The UEI PC 300 is a high performance, sixteen 18-bit-channel LOGGER with a maximum sampling frequency of 1 kHz per channel and a storage capacity of 500 million measurements, extensible to 1 billion measurements (supplied with complete software suite).

The factory configuration can be modified by the user or upon request:

• Rectifier transformer output voltage
• Rectifier transformer output current
• Electrode/structure potential
• 2 Hz sampling frequency
• Recording start on power-up

Note: A 2 Hz sampling frequency allows the recording of "On" times, "Off" times, transformer output faults and cathodic protection faults whose duration is higher than or equal to 2 seconds.

Storage

• Local storage on one SD type card with 2 GB capacity, extensible to 4 GB
• Download via an Ethernet network or direct SD card reading

Connectivity

The recorder is fitted as standard with the following ports:

• 1 Ethernet host 10/100 BT RJ45; UDP Protocol port 6334 and TCP/IP port 21 with configurable fixed IP (192.168.100.2 standard)
• 1 Ethernet Chain 10/100 BT RJ45
• 2 Free slots for I/O, analog cards, etc.
• 1 RS232 sub D 9 pin connector

Specifications

Operating temperature: –40°C to 85°C
Relative humidity: 0 to 90% without condensation
Vibration: 5g; from 10 to 500 Hz
Impact strength: 30g
Altitude: 70,000 feet
Power supply: 240 VAC; 3.5 W
Dimensions: 4.1” x 4.0” x 4.0”
